Engineered Power Distribution

SG-2000R

Switchgear solutions for protection, control and distribution across utility, industrial and data centre applications.

Capabilities

Wafr stocks and supplies switchgear for projects of any size, configured to your protection and distribution requirements across utility, industrial and data centre applications.

Wafr switchgear is designed, built and tested to applicable CSA, ANSI and IEEE standards, with configurations available for metal-clad, metal-enclosed and pad-mounted installations.

Base Rating

600 A to 4,000 A

High Voltage

5 kV to 38 kV

Low Voltage

208 V to 600 V

↓

Product Manual

↓

Product Brochure

↓

Product Warranty

Configurations

Product range

Select the family or configuration that best matches the application. Final ratings and options are confirmed on a project basis.

Common switchgear ratings:

Management prototype: sizes, ratings and lead-time indicators shown here are illustrative until confirmed in approved Wafr product documentation.

S22-M-RL-1600

Electrical equipment

35-50 days

Brochure Spec sheet

H*CD-G-1267

Mechanical equipment

8-10 wks

Brochure Spec sheet

WTB-2000

Thermal equipment

8-10 wks

Brochure Spec sheet

WTB-1500

Thermal equipment

6-8 wks

Brochure Spec sheet

WTB-1000

Thermal equipment

6 wks

Brochure Spec sheet

WTB-500

Thermal equipment

5-6 wks

Brochure Spec sheet

FR-1000Z

Thermal equipment

10-12 wks

Brochure Spec sheet

FR-750Z

Thermal equipment

8-10 wks

Brochure Spec sheet

Engineering

Technical specifications

Framework for technical review. Final values are confirmed from approved product sheets and project one-line requirements.

General product scope

Structured so engineering and procurement teams can review key ranges quickly.

Voltage class

Up to 38 kV

Bus rating

Project specific

Interrupting rating

Project specific

Frequency

50 / 60 Hz

Enclosure

Indoor / outdoor

Protection

Relay / breaker options

Standards

CSA / UL / ANSI / IEEE

Configuration

Standard & custom

Engineering notes

Available constructions include low-voltage, medium-voltage and metal-enclosed configurations.

Protection, metering and sectionalizing vary with the facility one-line design.

Submittals may include GA drawings, single-line diagrams and device schedules.

Documentation packages can include datasheets, manuals, drawings and certification records.

Compliance

Standards & certifications

Applicable standards and supporting certification documents can be surfaced directly on each product page.
