Engineered Power Distribution

SCB13-800

Three-phase dry-type distribution transformer, low noise and energy efficient, Dyn11 vector group with AN/AF cooling.

Capabilities

Wafr stocks and supplies transformers for projects of any size, customized however you need them, from data centre and industrial duty to standard commercial installations.

Wafr tamper-resistant, compartmentalized, liquid-filled transformers are designed, built and tested to applicable CSA, ANSI and IEEE standards. Configurations can include over-current protection and sectionalized switching for maximum control over the distribution system.

Rating

800 kVA

Voltage

10 / 0.4 kV

Standard

IEC 60076-11

↓

Product Manual

↓

Product Brochure

↓

Product Warranty

Configurations

Product range

Select the family or configuration that best matches the application. Final ratings and options are confirmed on a project basis.

Common padmount sizes:

Management prototype: sizes, ratings and lead-time indicators shown here are illustrative until confirmed in approved Wafr product documentation.

S22-M-RL-1600

Electrical equipment

35-50 days

Brochure Spec sheet

H*CD-G-1267

Mechanical equipment

8-10 wks

Brochure Spec sheet

WTB-2000

Thermal equipment

8-10 wks

Brochure Spec sheet

WTB-1500

Thermal equipment

6-8 wks

Brochure Spec sheet

WTB-1000

Thermal equipment

6 wks

Brochure Spec sheet

WTB-500

Thermal equipment

5-6 wks

Brochure Spec sheet

FR-1000Z

Thermal equipment

10-12 wks

Brochure Spec sheet

FR-750Z

Thermal equipment

8-10 wks

Brochure Spec sheet

Engineering

Technical specifications

Representative specification framework. Final numeric values and configuration options are confirmed from approved Wafr product sheets.

General product scope

Structured so engineering and procurement teams can review key ranges quickly.

Capacity range

30 kVA – 8,000+ kVA

Primary voltage

Project specific

Secondary voltage

Project specific

Frequency

50 / 60 Hz

Cooling

Dry / liquid filled

Enclosures

Indoor / outdoor

Standards

CSA / UL / IEEE / ANSI

Configuration

Standard & custom

Engineering notes

Primary and secondary voltages vary by application and utility context.

Configuration options include loop feed, radial feed and sectionalized switching.

Available accessories, protection and enclosure treatments can be added per project.

Documentation packages can include datasheets, manuals, drawings and certification records.

Compliance

Standards & certifications

Applicable standards and supporting certification documents can be surfaced directly on each product page.

CSA

Applicable by configuration

UL / cUL

Applicable by configuration

IEEE

Applicable by configuration

ANSI

Applicable by configuration

NEMA

Applicable by configuration

QA Docs

Applicable by configuration
